BioStation 3

The New Door Access Experience

BioStation 3 sets a new standard in access control, providing a new door access experience that enables improved security across all doors, for organizations of all sizes. This terminal is smaller than the previous model, yet it has the largest variety of features.

With highly advanced facial recognition, access credentials, and usability features, BioStation 3 makes it easier than ever to safely, securely, and conveniently protect an organization’s physical security and users’ personal data.

Multiple Contactless Access Methods

BioStation 3 provides multiple credential options. Choose from the most convenient authentication methods — all contactless and perfectly compatible with a post-pandemic world.

Perfect for Any Door, Any Business

BioStation 3 is easy to install and scale in any environment, from small offices to massive enterprise buildings. It features a 47% size reduction compared to Suprema’s previous bestselling facial recognition terminal, FaceStation F2.

· Slim and compact design
· Less wiring and quick installation through Wi-Fi and POE+ support
· Simple to add on new features via custom USB host connecting to SIM Slot, RS232, etc.
· Suitable for indoor and outdoor environments — the terminal is rated IP65 and IK06*

Fast and Smart AI Optimized for Facial Recognition Access

Suprema took its facial recognition technology to the next level. BioStation 3 is a high-tech edge device that can run AI algorithm locally. It uses an NPU, or Neural Processing Unit, to maximize the performance of its AI engine. Combined with Suprema’s domain knowledge and experience as a two-decade access control leader, BioStation 3’s NPU-optimized AI algorithm offers the highest standards in facial recognition accuracy and speed.

BioStation 3's NPU-optimized AI algorithm offers the highest standards in facial recognition accuracy and speed.

Non-stop Pass Through

Accurately and rapidly recognize moving faces in high-traffic areas

Compatible with Facial Variations

Use dynamic face templates to increase matching performance with faces wearing masks, glasses, hats, beards, different hairstyles, etc.

Protected Against Facial Spoofing

Detect fake faces, images, and photos to safeguard against facial spoofing

The Highest Level of Privacy Protection

BioStation 3 takes data protection very seriously.
· ISO/IEC 27001 certified to protect the privacy and biometric data
· Designed to comply with GDPR, one of the strictest privacy regulations
· Embedded with Secure Element(SE) to prevent cyber-attacks
· Completed penetration testing through a verified institution
· Provided with 'Face Template on Mobile'* credential

What is 'Face Template on Mobile'? – Own Your Own Data

Suprema’s exclusive authentication method ‘Face Template on Mobile’ lets users enroll into an access control system and store their face profile directly on their own mobile devices. This gives the users complete control over their own ID and their privacy. Users’ biometric data is not stored in company databases.

Easy Communication Across All Access Points

BioStation 3 enables integrated management over an entire access control system.
· Communicate seamlessly with all doors via VoIP Intercom
· Enable video monitoring via RTSP(Real Time Streaming Protocol)

Specifications

Model Name BS3-DB BS3-AWPB
RFID RF Option 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire EV1/EV2, FeliCa 125kHz EM, HID Prox & 13.56Mhz MIFARE, MIFARE Plus, DESFire EV1/EV2, FeliCa, iCLASS SE/SR/Seos
RF Read Range EM/HID iCLASS/MIFARE: 30mm, HID Prox/DESFire: 25mm, FeliCa: 15mm EM/HID iCLASS/MIFARE: 30mm, HID Prox/DESFire: 25mm, FeliCa: 15mm
Mobile Card NFC, BLE NFC, BLE
QR/Barcode Supported Supported
Biometrics Face Face
Protections Ingress Protection IP65 IP65
Vandal Proof IK06 IK06
Capacity  Max. User 100,000 100,000
Max. Credential (1:N) Face: 50,000 Face: 50,000
Max. Credential (1:1) Face: 100,000/ Card: 100,000/ PIN: 100,000 Face: 100,000/ Card: 100,000/ PIN: 100,000
Max. Text Log 5,000,000 5,000,000
Max. Image Log 50,000 50,000
Face  Recognition Distance 0.6~1.0m (23.6"~39") 0.6~1.0m (23.6"~39")
Recognition Height 1.4~1.9m (55.1"~74.8") 1.4~1.9m (55.1"~74.8")
Matching Speed Less than 0.3 sec Less than 0.3 sec
Live Face Detection Supported Supported
General CPU 1.5 GHz Quad Core 1.5 GHz Quad Core
Memory 32GB Flash + 4GB RAM 32GB Flash + 4GB RAM
Crypto Chip Supported Supported
LCD Type 5.5" IPS color LCD 5.5" IPS color LCD
LCD Resolution 720 x 1280 pixels 720 x 1280 pixels
Camera 2MP x 2EA (Visual, IR) 2MP x 2EA (Visual, IR)
Sound 16 bit 16 bit
Operating Temperature -20°C ~ 50°C (-4°F~122°F) -20°C ~ 50°C (-4°F~122°F)
Operating Humidity 0% ~ 80%, non-condensing 0% ~ 80%, non-condensing
Weight

Device: 370g

Bracket (including washer and bolt):90g

Device: 370g

Bracket (including washer and bolt):90g

Dimension (WxHxD, mm) 82.5mm x 171mm x 23.4mm 82.5mm x 171mm x 23.4mm
Tamper Supported Supported
Certificates KC, CE, UKCA, FCC, RCM (Compliance:RoHS, REACH, WEEE) KC, CE, UKCA, FCC, RCM (Compliance:RoHS, REACH, WEEE)
Interface Wi-Fi - Supported (802.11 b/g/n 2.4GHz)
Ethernet 10/100/1000 Mbps, auto MDI/MDI-X 10/100/1000 Mbps, auto MDI/MDI-X
RS-485 1ch Host or Slave (Selectable) 1ch Host or Slave (Selectable)
Wiegand 1ch Input and 1ch Output   1ch Input and 1ch Output
TTL Input 3ch Inputs 3ch Inputs
Relay 1 Relay 1 Relay
USB USB 2.0 (Host) USB 2.0 (Host)
Extended USB Supported Supported
PoE - Supported (IEEE 802.3 at compliant)
Intercom Supported Supported
Electrical Power DC 12V 2.5A, DC 24V 1.2A DC 12V 2.5A, DC 24V 1.2A

1)DESFire EV2 cards are supported by having backward compatibility of DESFire EV1 cards. CSN and smart card functions are compatible with BioStation 3.

2)RF read range will vary depending on the installation environment.

3)Requires a separate license.

4)The number of users registered without having any credential data.
